MAC97A 600V – 0.8A Triac

Description

Designed for use in solid state relays, MPU interface, TTL logic and any other light industrial or consumer application. Supplied in an inexpensive TO−92 package which is readily adaptable for use in automatic insertion equipment

Features:-

• One−Piece, Injection−Molded Package
• Blocking Voltage to 600 Volts
• Sensitive Gate Triggering in Four Trigger Modes (Quadrants) for all possible Combinations of Trigger Sources, and especially for Circuits that Source Gate Drives
• All Diffused and Glassivated Junctions for Maximum Uniformity of Parameters and Reliability
• These are Pb−Free Devices

Specifications:-

• Maximum Operating Temperature : 125 Deg C
• Mounting Type : Through Hole
• Pin Count : 3
• Model : MAC97A6
• Voltage – Off State : 400 V
• Current – On State : Max 600 mA
• Voltage – Gate Trigger : Max 1.5 V
• Current – Gate Trigger : Max 7 mA
• Current – Hold : Max 10 mA

Package Includes:-

1 x MAC97A 600V – 0.8A Triac
